THE FIBER MASTER
 |
The Characteristic of IFS-10
- Light and handy, user friendly, easy to operate
- Battery: Typical 350 cycles
- Illuminated keypad, utlra durable more than 1 Million times
- Lightweight only 2,3 kg
- Easy electrodes exchange
- Easy changeable Holder for Multi-functional Splicing
- Easy to clean the batterie
- Bright LED for night
- Heating oven with zoom window
WATERPROOF, DUSTPROOF;ANTI-SHOCK, WINDPROOF
|
|
MORE DETAIL
|
Specifications
| Weight (without battery) |
2,2 kg
|
Average Loss |
SM(0,02dB),MM(0,01dB), DS(0.04dB),NZDS(0,04dB)
|
| Splicing Method |
DACAS (Digital Analysis Core Alignement System)
|
Applicable fiber |
SM(G.652), MM(G.651),
DS (G.653), NZDS(G.655)G.657A and G.657B
|
| Splicing time SM fusion average |
9s / Quick Mode 7s
|
Coating Diameter |
100-1000 my
|
| Storage Condition |
-40 to 80°C, rel. hum. 95%
|
Cladding Diameter |
80-150my
|
| Operation enviroment |
0-5000m, -10 - +50°C,
|
Electrode Life Span |
> 2'500 times
|
| Splice memory |
max. 2000 records
|
Protection sleeve |
60mm, 40mm
|
| Splice programs |
100 user mode
|
Power supply |
AC 100-240V or DC 10-15V |
| Wind protection |
max. wind speed 15m/s
|
Size |
155x130x143mm
|
|
|
|
